Dymax ACCU-CAL 50 Radiometer 39561 without Lightguide Adapters or Simulator - 39561 RADIOMETER

Description

The Dymax ACCU-CAL 50 Radiometer delivers accurate, repeatable UV intensity and dose measurements for a wide range of light-curing applications. Designed for precision and ease of use, it helps engineers, operators, and quality professionals validate and monitor UV curing system performance.

Operating within the 320–395 nm wavelength range, the ACCU-CAL 50 measures light intensity up to 40 W/cm², making it ideal for both flood-lamp and spot-cure systems. Its NIST-traceable calibration ensures dependable accuracy for regulatory compliance, while the compact, battery-powered design allows convenient in-process monitoring on production lines or in laboratory environments.

This model is supplied without lightguide adapters or a simulator, offering a flexible solution for users who already own compatible Dymax system accessories.

Key Features

• High Accuracy Measurement: Provides precise UV intensity and dose readings for process validation.

• Wide Measurement Range: Detects UV energy from 1 mW/cm² up to 40 W/cm².

• Broad Spectral Sensitivity: 320–395 nm coverage for a wide variety of curing applications.

• User-Friendly Interface: Digital LCD screen displays real-time readings and dose totals.

• Traceable Calibration: NIST-certified calibration ensures consistent performance.

• Compact, Portable Design: Lightweight and battery-operated for use across multiple stations.

• Durable Sensor Construction: Tolerates up to 120 °C continuous exposure (200 °C peak).

• Versatile System Compatibility: Works with Dymax UV flood lamps, conveyors, and spot-cure systems.

Applications

• UV Curing Process Validation: For adhesives, coatings, and inks in industrial and laboratory setups.

• Production Quality Assurance: Ensures consistent light intensity across UV curing equipment.

• R&D and Testing Laboratories: Ideal for developing and optimizing UV-curable formulations.

• Preventive Maintenance: Monitors UV lamp performance to determine replacement schedules.

• Electronics & Medical Device Manufacturing: Supports reliable curing of critical assemblies.

Benefits

• Enhanced Process Control: Enables data-driven adjustments to ensure optimal curing performance.

• Improved Product Quality: Detects UV degradation before it affects output consistency.

• Regulatory Compliance: NIST-traceable readings support ISO and GMP documentation.

• Flexible Deployment: Suitable for cleanrooms, manufacturing lines, and R&D facilities.

• Operational Efficiency: Quick measurement and easy readout reduce downtime.

• Long Service Life: Built to withstand rigorous industrial use with robust calibration integrity.

Product Specs

Spectral Sensitivity	320 to 395 nm
Intensity Range	1 mW/cm² to 40 W/cm²
Intensity	1 mW/cm² (to three significant digits)
Dose	1 mJ/cm²
Optometer Temperature	+5 to +40 °C
Detector Temperature	120 °C continuous, 200 °C peak
Power Supply	Two (2) AA batteries
Battery Life	250 hours (auto shutoff after 1 hour)
Meter Dimensions	120 mm (L) × 65 mm (W) × 23 mm (T)
